Epson TM
U220 Reference Guide

D-2 Power Supply Unit Rev. E
D.2 PS-180
This power supply unit can be used with all models of the TM-U220.
D.2.1 Case specifications
❏ Size: 68 mm(D) × 136 mm(L) × 32 mm(H)
{2.68 (D) × 5.35 (L) × 1.26" (H)}
(excluding projections) Refer to the figure below.
❏ Mass: Approx. 0.4kg (excluding the AC cable)
❏ Material: Flame-resistance grade: V0
❏ Color: Black (matte)
Case specifications
D.2.2 Usage cautions
❏ AC cable Select an AC cable that satisfies the following conditions
• Product safety standards
• Plug with PE terminal
❏ Ground connection Ground certainly for safety
68
32
136

Epson TM
U220 Specifications

General

Print speed	4.7 lps
Character size	1.6 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	57.5±0.5/69.5±0.5/76±0.5 x 83.0
Dimensions (WxDxH)	160 x 286 x 157.5 mm
Certification	WEEE/RoHS
Mean time between failures (MTBF)	180000 h
Parallel connector	Yes
Standard interfaces	Parallel
