Epson TM
U220 Reference Guide

3-8 Setup Rev. E
3.3.2.1 Installing rhe Roll Paper for Type B, D
1. Using scissors, cut the leading edge of
the roll paper, as shown in the left figure.
2. Turn on the printer and open the roll
paper cover by using the tab, as shown in
the left.
3. Insert the roll paper, as shown on the left.
Note:
Note the direction the paper comes off the
roll, as shown below.
When using 2-ply roll paper, be sure that the
top and bottom sheets are aligned at the paper
exit. See the below illustration.
4. Close the roll paper cover.
Tab

Epson TM
U220 Specifications

General

Print speed	4.7 lps
Character size	1.6 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	57.5±0.5/69.5±0.5/76±0.5 x 83.0
Dimensions (WxDxH)	160 x 286 x 157.5 mm
Certification	WEEE/RoHS
Mean time between failures (MTBF)	180000 h
Parallel connector	Yes
Standard interfaces	Parallel
