Epson TM
U220 Reference Guide

3-12 Setup Rev. E
Note:
Since the printer does not feed even if the roll paper cover is open when the printer is turned off, make sure
not to pinch the paper when the cover is closed.
Do not open the roll paper cover during printing or paper feeding.
When using the printer, be sure to cut the roll paper with the manual cutter after paper feeding is
complete.
3.3.2.3 Replacing the Roll Paper
1. Turn on the printer and open the
roll paper cover by using the tab,
as shown.
2. Types B and D: Remove the used roll paper core.
3. Type A only: Remove the take-up
spool, and open the unit by using
the unit open lever, as shown; then
remove the used roll paper core.
4. Insert new roll paper. See the section “Installing the Roll Paper for Type A”
(page 3-9).
Tab

Epson TM
U220 Specifications

General

Print speed	4.7 lps
Character size	1.6 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	57.5±0.5/69.5±0.5/76±0.5 x 83.0
Dimensions (WxDxH)	160 x 286 x 157.5 mm
Certification	WEEE/RoHS
Mean time between failures (MTBF)	180000 h
Parallel connector	Yes
Standard interfaces	Parallel
