How to Install the Printer on a Wall with the WH-10
WH-10 is a option for the TM printer series, with it you can install a TM-U220 on a wall. This
section describes how to install wall hanging TM-U220. See the “WH-10 installation Manual“ for
details.
B.1 The Procedure
B.1.1 Precautions
❏ Static electricity may cause cut paper to adhere to the printer case.
(This static electricity will not affect the operation of the printer.)
B.1.2 Unpacking
Open the package and confirm that it contains all of the parts listed in the illustration. If any
parts are missing or damaged, please contact your dealer for assistance.
Depending on the conditions during storage and shipping, some rust may form around the
edges of the wall-mount or brackets. This may be removed with sandpaper.
brackets (2 pieces)
installation manual
screws for brackets (3×12)
(4 pieces)
wall-mount (note: screws for
wall-mount not included; see
the installation section.)
control panel sheets
Please attach the appropriate sheet.
screws (3×10)
Note:
Other parts are packed for
other TM printer series.
roll paper holder for
hanging bracket
cam
screws (3×6) (5 pieces)
Note: 4 of the screws are
used for attaching the
brackets
3
2
4
1
3
2
4
1
3
2
4
1
3
2
4
1
