Epson TM
U220 Reference Guide

3-10 Setup Rev. E
4. Insert the roll paper, as shown in the left.
Note:
Note the direction the paper comes off the
roll, as shown in following
When using 2-ply roll paper, be sure that the top
and bottom sheets are aligned at the paper exit.
See below illustration.
5. Close the roll paper cover.
6. If you are not using a take-up spool, pull out a small amount of roll paper and close
the roll paper cover; then tear off the paper with the manual cutter. You can skip
steps 6 through 11.
7. When using 2-ply roll paper, pull out the
roll paper to the bottom front of the
printer as a guide, as shown in left.

Epson TM
U220 Specifications

General

Print speed	4.7 lps
Character size	1.6 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	57.5±0.5/69.5±0.5/76±0.5 x 83.0
Dimensions (WxDxH)	160 x 286 x 157.5 mm
Certification	WEEE/RoHS
Mean time between failures (MTBF)	180000 h
Parallel connector	Yes
Standard interfaces	Parallel
