Freestanding Unit (DFS730) Installation
G1 Product Dimensions
G2 Hearth and Clearances
A Hearth is not required, however it may be used for decorative purposes or for protection of sensitive
flooring. The hearth should not obscure the air inlet of the fire.
Do not place items or furnishings ontop of the freestanding fireplace, and ensure soft furnishings do
not come in contact with the freestanding fireplace.
G3 Locating the DFS730
505mm
735mm*
381mm
124mm
753mm
368mm* 368mm*
*Not including Lid Overhang
175mm
315mm
50mm
50mm 50mm
