Escea DF960 - C2 Flue Configuration (if more than 4 M Flue Length Is Required)

B
A C D E F G SERVICE
16
C2 Flue Configuration (If more than 4m flue length is required):
If your flue system is greater than 4m long (as shown in diagrams below), then a flexible flue with
condensate trap and rigid PP tube flue lengths is required.
4m
Ø80mm / Ø100mm
Flexible Flue
1.2m Co-axial Flue
Vertical Powerflue
12m MAX
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
PP Tube
FOR MORE INFORMATION ON
INSTALLATION OF THE POLYPRO
FLUE, SEE ‘POLY PRO FLUE
INSTALLATION INSTRUCTIONS’
AVAILABLE ON:
WWW.ESCEA.COM
OR SUPPLIED WITH THE FLUE.
FOR POLY PRO COMPONENT GUIDES,
THESE ARE AVAILABLE ON:
WWW.ESCEA.COM
TITLED:
HORIZONTAL FLUE COMPONENT
GUIDE &
VERTICAL FLUE COMPONENT GUIDE
4m
ESCEAWALL
TERMINAL
12m MAX
Ø80mm / Ø100mm
PP Tube
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
Flexible Flue
