Escea DF960 - A3 Product Dimensions

B
ACDEFGSERVICE
9
A3 Product Dimensions
Note: All outside dimensions taken from the appliance are with the standos attached
*Slim Fascia Dimensions.
A
E*
D*
C
B
A B C D* E*
DF700 693mm 387mm 596mm 711mm 593mm
DF960 943mm 402mm 596mm 961mm 593mm
END OF SECTION A
By the end of this section, you should have:
□ A framed false cavity
OR
□ A masonry cavity sized to suit the appliance
