Essilor E-Tess Tracer
33 4- Using the e-Tess tracer
Click on key D.
- To call the job on screen
Select the required job in the list,
Click on key E, you return to the tracing screen.
3.5. SHAPE ALTERATION
Shape alteration can be accessed from the dimension screen after tracing or recalling a job, or
directly if you choose "Shape alteration" tracing mode (see Chapter 4.3.).
The following screen is displayed:
1. Select the eye you want to alter, A,
2. Start the alteration. Two methods are available:
a. Method 1
Select the dimension you want to modify, B:
Use keys C and D to increase or decrease the chosen dimension.
B-dimension. A-dimension.
Upper ½ B-dimension. Right ½ A-dimension.
Lower ½ B-dimension. Left ½ A-dimension.
Scaling.
Display zone
