Essilor E-Tess Tracer
Adding a standard
This function allows you to save in your e-Tess tracer information concerning a frame standard used for
calibration and the calibration check.
a. Step 1: from your PC
1. Insert the Check CD-ROM, CD No. 2, supplied with the standard you want to add in your tracer,
N.B. The number indicated on your standard must be the same as that indicated on the CD.
2. Insert the USB stick supplied by Essilor on a USB port of your PC,
3. Wait for a few seconds until Windows detects the accessory,
4. In the start menu, click on My PC, your stick must be displayed: "removable disk",
5. Double-click on this disk,
6. Copy the files of type M66173OD.TXT and M66173OG.TXT on the root directory of the CD-ROM to
the root of the USB stick,
7. Close the USB removable disk,
8. At the bottom right of your screen, request the removal of your USB storage peripheral,
9. Wait for confirmation, then remove the stick from your PC,
b. Step 2: from your E-Tess tracer
1. Power up your tracer, switch in position 1,
2. After the initialisation phase, insert the USB stick on the external USB port of your tracer, connector
(3),
3. Press to access the configuration/maintenance menu,
4. Select the "Import-Export" function ,
5. Select the import pattern, then validate
,
6. When the import is finished, e-Tess is ready for a job, your new standard will be available for your
calibration operations (see Chapters 5.1. and 5.2).
If an error occurred during the operation, refer to Chapter 7.
7. Remove the stick from your tracer.
Software update
IMPORTANT
During a software update, your tracer returns to the default configuration:
Configure the communication parameters, see Chapter 2.3.
Choose your language, see Appendix A.
