Cross drum brake (service brake)
• Brake while in motion by pulling the brake lever
upwards.
Cross drum brake (parking brake)
A
• Activate the parking brake by pulling the brake lever
upwards and pressing in button A.
• Release by pulling the lever upwards.
User manual
Push handles/bow handle, height adjustable
Loosen the knobs/release the locking handles. Set desired
height. Ensure that the push handles are locked in the
correct position, tighten the knobs/lock the locking
handles.
Make sure the knobs/locking handles are properly
tightened/locked and that the safety buttons have
popped out below the brackets.
The bow handle must be removed before the chair can be
folded.
Leg support
The leg supports can be lifted off/swung to the side if
needed. Lockable leg supports by pushing the red button
(A).
To fasten the lockable leg supports press down on the red
button (A), put the leg support into place and release the
button. The leg support is now locked (B).
Check that the leg supports are locked before lifting.
Back support mod. 2
Loosen the knob (A) and press the
red plastic washer. Then as above.
