Etac Cross 5 - Settings Back Support 3 A; Adjusting Back Support Angle

32
Etac / Cross 5 / www.etac.com
2°
1 2
3
20 Nm
Cross 5 Cross 5 XL
1. Loosen the nut.
2. Adjust the back support angle. Use the position mark-
ings to obtain the same back support angle on the right
and left sides respectively.
3. Tighten the nut.
Tipping risk! Always check the anti-tip function after
adjustments!
6. Settings back support 3A
Adjusting back support angle
13 mm
