22
Etac / Cross 5 / www.etac.com
3–7 cm
Click!
Click!
Rear wheel with quick release
When assembling, always make sure that
the quick-release button in the hub
springs out properly. Test by pulling the
wheel.
Folding
• If a bow handle and/or cross brace is
mounted they should be removed.
• Flip up the foot supports.
• Lift up the seat.
User manual
Unfolding
• Push down on one side of the seat frame,
using the whole of the flat of the hand.
• Lower the foot supports.
Risk of pinching! Do not hold the seat
tube while unfolding.
Anti-tips
• The anti-tips can be flipped up.
• Ensure the locking function
works properly when activa-
ting the anti-tip.
• After any adjustments on your wheelchair, always
ensure that you check the function of the anti-tips.
If necessary to adjust, please contact your dealer or
your Technical Aids Centre.
Handling
