ES4455.2 Load Carrier Board - User’s Guide26
Properties and Functions ETAS
2.2.4 ES4452.1 Load Carrier Board for 4 RB GDI Injectors, CVO
The ES4452.1 Load Carrier Board for 4 RB GDI Injectors, CVO (Fig. 2-7) consists
of the ES4455.2 Load Carrier Board and a load module installed on it for simu-
lating four GDI injector loads. The load board is connected with the load module
via a ribbon cable.
Fig. 2-7 ES4452.1 Load Carrier Board for 4 RB GDI Injectors, CVO
2.2.5 ES4453.1 Load Carrier Board for 4 RB HDEV6 GDI Injectors, CVO
The ES4453.1 Load Carrier Board for 4 RB HDEV6 GDI Injectors, CVO (Fig. 2-8)
consists of the ES4455.2 Load Carrier Board and a load module installed on it for
simulating four GDI injector loads. The load board is connected with the load
module via a ribbon cable.
Fig. 2-8 ES4453.1 Load Carrier Board for 4 RB HDEV6 GDI Injectors, CVO
2.2.6 ES4457.1 Load Carrier Board for 4 RB CRS Injectors, VCC and VCA
The ES4457.1 Load Carrier Board for 4 RB CRS Injectors, VCC and VCA (Fig. 2-9)
consists of the ES4455.2 Load Carrier Board and a load module installed on it for
simulating four CRS injector loads. The load board is connected with the load
module via a ribbon cable.
Fig. 2-9 ES4457.1 Load Carrier Board for 4 RB CRS Injectors, VCC and VCA
