3.4.2 "X1 Measure" Plug Connector
Type: HD15 pole (female)
Counterplug: HD15 pole (male)
The pin assignment of "X1 Measure" is as follows:
Tab. 3-9 Pin assignment of "X1 Measure"
Connection:Pin Signal Name CO200
Meas 1 I_Dig_Out_1 d10
Meas 2 I_Dig_Out_2 z12
Meas 3 I_Dig_Out_3 b12
Meas 4 I_Dig_Out_4 d12
Meas 5 Online_Probe z14
Meas 6 Online_Probe_Ref b14
Meas 7 not used d14
Meas 8 not used z16
Meas 9 GND b16
Housing
