ES4455.2 Load Carrier Board - User’s Guide24
Properties and Functions ETAS
2.2 Figures of ES4455.2 and its Mounted Variants ES4450.3, ES4451.4,
ES4452.1, ES4453.1, ES4457.1 and ES4458.1
2.2.1 ES4455.2 Load Carrier Board
The following figure shows the front plate on the left and the rear side of the
ES4455.2 Load Carrier Board on the right. The variants ES4450.3, ES4451.4,
ES4452.1, ES4453.1, ES4457.1 and ES4458.1 mounted with load modules have
the same front plate and the same backplane connector. On the front plate, the
label of the blue type plate is adapted to the respective variant.
Fig. 2-3 Front plate (left) and rear side of the ES4455.2 Load Carrier Board
Fig. 2-4 ES4455.2 Load Carrier Board
