ETAS ES4455.2 - Connections and Plug Connections for Installation in the ES5300.1-A Housing or in the ES5300.1-B Housing

ES4455.2 Load Carrier Board - User’s Guide 43
ETAS Connections and Connectors
The assignment of the connections of "Meas 8-2" with mounting of Slot_0 with
ES4450.3, ES4451.4, ES4452.1, ES4453.1, ES4457.1 and ES4458.1 is as follows:
Tab. 3-7 "Meas 8-2" pin assignment
3.4 Connections and Plug Connections for Installation in the ES5300.1-
A Housing or in the ES5300.1-B Housing
Installing the ES4455.2 Load Carrier Board and its variants ES4450.3, ES4451.4,
ES4452.1, ES4453.1, ES4457.1 and ES4458.1 mounted with load modules in the
ES5300.1-A Housing or the ES5300.1-B Housing requires the ES5372.1 Carrier
for ES4455 Load Boards.
Tab. 3-9 on page 46 shows the backplane side of the ES5372.1 Carrier for
ES4455 Load Boards. The plug connectors Load and Meas enable a connection
of the Load Carrier Boards ES4450.3, ES4451.4, ES4452.1, ES4453.1, ES4457.1
and ES4458.1 to the motor ECU.
Connection:Pin Slot: Signal name Backplane connection
ES4408.1
Meas 8-2:1 Slot0:I_Dig_Out_1 Slot 0:d10
Meas 8-2:2 Slot0:I_Dig_Out_2 Slot 0:z12
Meas 8-2:3 Slot0:I_Dig_Out_3 Slot 0:b12
Meas 8-2:4 Slot0:I_Dig_Out_4 Slot 0:d12
Meas 8-2:5 Slot0:Online_Probe Slot 0:z14
Meas 8-2:6 Slot0:Online_Probe_Ref Slot 0:b14
Meas 8-2:7 Slot0:not used Slot 0:d14
Meas 8-2:8 Slot0:not used Slot 0:z16
Meas 8-2:9 Slot0:GND Slot 0:b16
Housing
