ES4455.2 Load Carrier Board - User’s Guide44
Connections and Connectors ETAS
Fig. 3-5 Plug connectors "X1 Measure" and "X2 Load" on the backplane
side of the ES5372.1 Carrier for ES4455 Load Boards.
X1 Measure
X2 Load
1
8
10
5
6111
15
