ETAS ES4455.2 - X2 Load Plug Connector

ES4455.2 Load Carrier Board - User’s Guide 45
ETAS Connections and Connectors
3.4.1 "X2 Load" Plug Connector
Type: Hybrid-DSUB FM8W8P-5852 (male)
Manufacturer: FCT
Counterplug: Hybrid DSUB 8W8 (female)
The pin assignment of "X2 Load" is as follows:
Tab. 3-8 "X2 Load" pin assignment
Pin Signal CO 200
A1 Load 1+ z18
b18
d18
A2 Load 1– z20
b20
d20
A3 Load 2+ z22
b22
d22
A4 Load 2– z24
b24
d24
A5 Load 3+ z26
b26
d26
A6 Load 3– z28
b28
d28
A7 Load 4+ z30
b30
d30
A8 Load 4– z32
b32
d32
Housing
