ES4455.2 Load Carrier Board - User’s Guide 39
ETAS Connections and Connectors
The pin assignment is as follows:
Tab. 3-2 "Load 7" pin assignment
The plug connector "Load 8-1" enables access to the plug-in card in slot 1.
Pin Signal Backplane connection
A1 Load 1+ Slot 2:z18
Slot 2:b18
Slot 2:d18
A2 Load 1– Slot 2:z20
Slot 2:b20
Slot 2:d20
A3 Load 2+ Slot 2:z22
Slot 2:b22
Slot 2:d22
A4 Load 2– Slot 2:z24
Slot 2:b24
Slot 2:d24
A5 Load 3+ Slot 2:z26
Slot 2:b26
Slot 2:d26
A6 Load 3– Slot 2:z28
Slot 2:b28
Slot 2:d28
A7 Load 4+ Slot 2:z30
Slot 2:b30
Slot 2:d30
A8 Load 4– Slot 2:z32
Slot 2:b32
Slot 2:d32
Housing ES4408 protective
ground
