Eureka E75/2 - Page 14

15
19
20
1. Solution adjustment lever
2. Squeegee lifting lever
3. Control panel
4. Brush plate lifting pedal
5. Brush plate pedal release lever
6. Rear anchor point
7. Electric brake manual release
8. Solution tank
9. Brush release peg
10. Rear wheel
11. Machine rear anchoring point
12. Solution tank level
13. Squeegee inclination adjustment knob
14. Solution tank filling cap
15. Solution tank discharge hose
16. Squeegee vacuum pipe
17. Recovery tank drain pipe
18. Recovery tank
19. Material collection box
20. Recovery tank cover
