EVCO S.p.A. c-pro 3 | Hardware manual ver. 2.0 | Code 114CP3E204
page 48 of 86
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
TSEG2 1 7 - - - 7 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
SJW 0 3 - - - 0 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
BTR(1) 1 15 - - - 15 reserved
Networks /
UART1
(1)
Address 1 247 - - - 1
local (or of the controller) Modbus node
address in a RS-485 network wired on the
RS-485 port
Networks /
UART1
(1)
Baud Rate - - - - - - - - - 9600
Modbus communication baud rate in a
RS-485 network wired on the RS-485 port
1200 = 1,200 baud
2400 = 2,400 baud
4800 = 4,800 baud
9600 = 9,600 baud
19200 = 19,200 baud
28800 = 28,000 baud
38400 = 38,400 baud
57600 = 57,600 baud
Networks /
UART1
(1)
Parity - - - - - - - - - EVEN
Modbus communication parity in a RS-485
network wired on the RS-485 port
NONE = no parity
ODD = odd
EVEN = even
Networks /
UART1
(1)
Stop - - - - - - - - - 1 BIT
Modbus communication stop bit number in a
RS-485 network wired on the RS-485 port
1 BIT = 1 bit
2 BIT = 2 bit
