EVCO S.p.A. c-pro 3 | Hardware manual ver. 2.0 | Code 114CP3E204
page 53 of 86
Parameters (1) AI3 - - - - - - - - - NTC
kind of probe analog input 3
PTC = PTC probe
NTC = NTC probe
0-20mA = 0-20 mA transducer
4-20mA = 4-20 mA transducer
0-5V = 0-5 V ratiometric transducer
0-10V = 0-10 V ratiometric transducer
PT1000 = Pt 1000 probe
Parameters (1) AI4 - - - - - - - - - NTC
kind of probe analog input 4
PTC = PTC probe
NTC = NTC probe
0-20mA = 0-20 mA transducer
4-20mA = 4-20 mA transducer
0-5V = 0-5 V ratiometric transducer
0-10V = 0-10 V ratiometric transducer
PT1000 = Pt 1000 probe
Parameters (1) AI5 - - - - - - - - - NTC
kind of probe analog input 5
PTC = PTC probe
NTC = NTC probe
0-20mA = 0-20 mA transducer
4-20mA = 4-20 mA transducer
0-5V = 0-5 V ratiometric transducer
0-10V = 0-10 V ratiometric transducer
PT1000 = Pt 1000 probe
Parameters (1) AI Err Time 0 240 s 2
analog inputs time-out (after this time without
communication with an analog input, the
controller signals the analog input error)
Parameters (1) AO1 - - - - - - - - - PWM
kind of signal analog input 1
PWM = PWM (Pulse With Modulation)
Parameters (1) AO2 - - - - - - - - - 0-10V
kind of signal analog input 2
0-20mA = 0-20 mA
4-20mA = 4-20 mA
0-10V = 0-10 V
Parameters (1) AO3 - - - - - - - - - 0-10V
kind of signal analog input 3
0-20mA = 0-20 mA
4-20mA = 4-20 mA
0-10V = 0-10 V
Parameters (1) CosPhi 10us - - - - - - - - - - - - reserved
