Evco c-pro 3 Series User Manual

EVCO S.p.A. c-pro 3 | Hardware manual ver. 2.0 | Code 114CP3E204
page 56 of 86
Parameters (2)
[ press button
RIGHT to
show it ]
Debug Baud - - - - - - - - - - - - 19200
baud rate for the debug
19200 = 19,200 baud
28800 = 28,800 baud
38400 = 38,400 baud
57600 = 57,600 baud
76800 = 76,800 baud
115K2 = 115,200 baud
Networks / CAN
Bus
MyNode 1 127 - - - 1 local (or of the controller) CAN node address
Networks / CAN
Bus
Master - - - - - - - - - YES
enabling the operation as master in a CAN
network
YES = yes
Networks / CAN
Bus
Baud - - - - - - - - - 20K
CANbus communication baud rate
20K = 20,000 baud
50K = 50,000 baud
125K = 125,000 baud
500K = 500,000 baud
Networks / CAN
Bus
Timeout 1 60 s 5
remote (or with a device in the network)
CANbus communication time-out (after this
time without CANbus communication with a
device, it is excluded by the network)
Networks / CAN
Bus
NetworkNode [ 1 ] 0
[ 32 ]
127
- - - [ 1 ] 99
address of a remote (or of a device in the
network) CAN node; example for [ 1 ] 2:
[ 1 ] = node
2 = node’s address
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
TSEG1 0 63 - - - 31 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
TSEG2 1 7 - - - 7 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
SJW 0 3 - - - 0 reserved
