Parameters (1) AI3 - - - - - - - - - NTC
kind of probe analog input 3
PTC = PTC probe
NTC = NTC probe
0-20mA = 0-20 mA transducer
4-20mA = 4-20 mA transducer
0-5V = 0-5 V ratiometric transducer
0-10V = 0-10 V ratiometric transducer
PT1000 = Pt 1000 probe
Parameters (1) AI Err Time 0 240 s 2
analog inputs time-out (after this time without
communication with an analog input, the
expansion signals the analog input error)
Parameters (1) AO1 - - - - - - - - - PWM
kind of signal analog input 1
PWM = PWM (Pulse With Modulation)
Parameters (1) AO2 - - - - - - - - - 0-10V
kind of signal analog input 2
0-20mA = 0-20 mA
4-20mA = 4-20 mA
0-10V = 0-10 V
Parameters (1) AO3 - - - - - - - - - 0-10V
kind of signal analog input 3
0-20mA = 0-20 mA
4-20mA = 4-20 mA
0-10V = 0-10 V
Parameters (2)
[ press button
RIGHT to
show it ]
I/O Timeout 1 240 s 60
time-out of the CANbus communication for
the test of the remote values of the I / O
(after this time without CANbus
communication, the I / O of the expansion is
disabled)
Networks / CAN
Bus
MyNode 1 127 - - - 2
local (or of the expansion) CAN node
address
Networks / CAN
Bus
Master - - - - - - - - - YES
enabling the operation as master in a CAN
network
YES = yes
Networks / CAN
Bus
Baud - - - - - - - - - 20K
CANbus communication baud rate
20K = 20,000 baud
50K = 50,000 baud
125K = 125,000 baud
500K = 500,000 baud
Networks / CAN
Bus
NetworkNode [ 1 ] 0
[ 32 ]
127
- - - [ 1 ] 99
address of a remote (or of a device in the
network) CAN node; example for [ 1 ] 2:
[ 1 ] = node
2 = node’s address
