EVCO S.p.A. c-pro 3 | Hardware manual ver. 2.0 | Code 114CP3E204
page 64 of 86
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
TSEG1 0 63 - - - 31 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
TSEG2 1 7 - - - 7 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
SJW 0 3 - - - 0 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
BTR(1) 1 15 - - - 15 reserved
Diagnostic FRAM parameter available in read only modality
non volatile memory status
ok = not in error
err = in error
Diagnostic 5V Ratio parameter available in read only modality
status of the power supply voltage of the
ratiometric transducers
ok = not in error
err = in error (because of out of
range voltage)
Diagnostic 24V Sensor parameter available in read only modality
status of the power supply voltage of the
0-20 mA / 4-20 mA / 0-10 V transducers
ok = not in error
err = in error (because of out of
range voltage)
Main time parameter available in read only modality
main cycle time of the application software
(in milliseconds)
Debug
[ Algo ]
Int. time parameter available in read only modality
interrupt cycle time of the application
software (in milliseconds)
rx parameter available in read only modality number of packages in transmission
Debug
[ CAN bus ]
tx parameter available in read only modality number of packages in reception
