u
Reassemble
The
Arpus
I
9.
Position the
bottom
cover
in
place
against
the
front
bezel.
Make
sure
that
the
mother
board
and
U
CPU
board
fit
in
the
grooves
in
the
bottom
cover.
Make
sure
that
the
high
voltage
(HV)
wire
is
routed
correctly
and
not
pinched
by
the
yoke
support.
The
high
voltage
wire
must
run
through
the
Uslot
in
the
yoke
clamp.
Secure
the
bottom
cover
to
the
front
bezel
and
rear
cover
with
four
flat-head
screws.
U10.
Secure
each
side
panel
in
place
with
10
flat-head
screws.
The
left
side
cover
has
a
small
rubber
bumper
on
the
inside
which
is
positioned
over
the
daughter
board.
I
[
NOTE
Two
different
length
screws
are
used
on
each
side
panel.
The
short
screws
go
at
the
ends
of
the
I
I
panel
and
the
longer
screws
in
the
middle.
I
12.2.2
Adjusting
the
Swash
Plates
in
7000
Although
these
adjustments
are
made
with
the
unit
powered
on,
disconnect
power
to
the
unit
before
disassembling
or
reassembling
it.
Necessary
Tools:
Small
phillips
head
screwdriver
Glyptol
or
clear
nail
polish
Disassemble
The
Argus
Ul.
The
bottom
panel
is
held
in
place
with
10
screws:
eight
3/16
inch
screws
and
two
1/8
inch
screws.
The
1/8
inch
screws
are
marked
in
red.
Note
their
location,
then
remove
all
ten
screws
to
remove
the
bottom
panel.
U
2.
Remove
the
top
panel
by
first
removing
the
ten
screws
that
secure
it
to
the
unit.
U3.
Remove
the
screws
securing
the
left
cover
to
the
front
bezel
and
rear
cover,
and
remove
the
left
cover.
This
is
the
side
nearest
to
the
shorting
plug
jack.
||
4.
At
this
point the
swash
plates
can
be
seen
on
the
back
of
the
yoke.
(Refer
to
Figure
15
on
page
55.)
Adjust
The
Swash
Plates
U
5.
Connect
the
Argus
to
a
11-30
volt
power
source
and
power
the
unit
on.
|
|
WARNING
The
high
voltage
wire
carries
8000
volts!
This
voltage
can
cause
a
lethal
shock.
[\
CAUTION
I
Do
not
pull,
pinch,
nick,
or
otherwise
damage
the
high
voltage
lead
that
runs
from
the
power
|j
supply
to
the
side
of
the
CRT
display.
Damaging
the
wire
or
the
insulation
at
either
end
can
cause
a
catastrophic
failure
inflight.
I
i
M
Argus
Maintenance
Manual
Part
#5006
July,
1993
Page
61
