15 HOMEDEPOT.COM
Please contact Everbilt at 1-844-883-1872 for further assistance.
Deep Well Installation (continued)
4
Sliding the pipe assembly into
the well
NOTE: If use PVC pipe to connect, a 1 in. x 3 in.
nipple is required.
the assembly with a pipe clamp (not included) to prevent the
assembly from sliding down into the well.
Keep the 1 in. pipe 2 in. shorter than the 1-1/4 in. pipe.
depth to water.
2 in.
5
Slide a (HH) 4 in. well seal over the
Remove the pipe clamp and slide the (HH) 4 in. well seal
(sold separately) over the PVC or Flexible pipe and onto the
well casing (not shown).
The PVC or Flexible Pipe should extend approximately 12
in. from the well seal, depending on the height of the pump
placement.
Tighten the well seal until the rubber gaskets are tight
against the well casing and the PVC pipe.
~12 in.
(HH) 4 in. Well Seal
To Next Page
