HD2014, HD2012, HD2011 Video Passport
TM
1RU Multi-Path Video Converter, Frame Synchronizer and Decoder
Page 2-10 Revision 0.1 INSTALLATION
2.1.8. Composite Analog Video Connections
CVBS IN Y/G IN: Connection for composite analog video (NSTC/PAL) input signals with 75 ohm
termination. When connecting component analog video to the HD201x, connect the
Y/G channel of the component signal to this BNC.
CVBS OUT Y/G OUT: Connection for composite analog video (NSTC/PAL) output signals with 75 ohm
impedance. The CVBS OUT Y/G BNC is internally connected to the output of PATH 1.
When utilizing the component analog output of the HD201x, this BNC will supply the
Y/G element of the component analog video signal.
2.1.9. Flex Processing Module Connectors
RIGHT FLEX: The Flex Left slot allows the user to expand the HD201x processing capabilities.
Functionality depends on the installed flex module. For example, the FL-HIO enables
the use of FLEX LEFT BNC1-3 as three additional and individually configurable HD/SD
SDI input/outputs and the FL-CD3 enables the use of FLEX LEFT BNC1-3 as 3x
additional composite analog video inputs.
LEFT Right: The Flex Right slot allows one to expand the HD2014/12/11 processing capabilities.
Functionality depends on the installed flex module. For example, the FR-HIO enables
the use of FLEX RIGHT BNC1-3 as three additional and individually configurable
HD/SD SDI input/outputs and the FR-CE3 enables the use of FLEX RIGHT BNC1-3 as
3x additional composite analog video outputs.
Flex Right Out 1 is internally connected to the output of PATH2.
Flex Right Out 2 is internally connected to the output of PATH3.
Flex Right Out 3 is internally connected to the output of PATH4.
2.1.10. Optical Connections
SFP IN: SFP fiber input cage accepting 2x Dual SFP fiber RX.
The HD201x supports up to 4 fiber input signals (2x dual RX modules).
Dual SFP receiver modules may be purchased as a HD201x accessory.
SFP OUT: SFP fiber input cage accepting 2x Dual SFP fiber TX.
The HD201x supports up to 4 fiber output signals (2x dual TX modules).
Dual SFP transmit modules may be purchased as a HD201x accessory.
In the HD2014,
SFP 1 Out is internally connected to the output of PATH1.
SFP 2 Out is internally connected to the output of PATH2.
SFP 3 Out is internally connected to the output of PATH3.
SFP 4 Out is internally connected to the output of PATH4.
In the HD2011 and HD2012,
SFP 1 Out is internally connected to the output of PATH1.
SFP 2 Out is internally connected to the output of PATH2.
SFP 3 Out is internally connected to the output of PATH1.
SFP 4 Out is internally connected to the output of PATH2.
