HD2014, HD2012, HD2011 Video Passport
TM
1RU Multi-Path Video Converter, Frame Synchronizer and Decoder
Page 5-26 Revision 0.1 FRONT PANEL OPERATION
5.1.2.47. Viewing the CDP Parser
Each conversion path in the HD201x monitors that status of cdp captions parser on incoming video.
This controls reports the status of the cdp parser.
VIDEO
Processing
Converter
Path 1
Video Monitor
CdpParser
This control displays information on the CDP Parser.
5.1.2.48. Viewing the External Genlock Standard
Each conversion path in the HD201x monitors that status of selected reference. The EXT GENLOCK
STANDARD control reports the status of the applied reference.
VIDEO
Processing
Converter
Path 1 to 4
Video Monitor
extGenlockStandard
---
This control displays video delay information.
5.1.2.49. Viewing the Video Delay
Each conversion path in the HD201x monitors the video processing delay. The VIDEO DELAY control
reports the status of the processing path video delay.
VIDEO
Processing
Converter
Path 1 to 4
Video Monitor
Video Delay
This control displays video delay information.
5.1.3. Configuring the Analog In Controls
The controls under the Analog In menu allow the user to set parameters for the composite analog input
for the HD201x.
5.1.3.1. Configuring the Analog Video Source Select
Under the Source Select control, the user will be able to select whether the source of analog video is
composite analog video or component analog video. At the time of writing only composite analog video
is supported in the HD201x series.
