HD2014, HD2012, HD2011 Video Passport
TM
1RU Multi-Path Video Converter, Frame Synchronizer and Decoder
Page 5-22 Revision 0.1 FRONT PANEL OPERATION
0 to 1079
5.1.2.35. Setting the Output H Start
The Output H Start control determines where to place the selected portion of the input image onto the
output video raster. The Output H Start control defines the starting horizontal position for the video
content on the output image raster. The input image will be stretched to fill the width defined by Output
H Start and Output H Stop. Areas of the output image raster not filled with video content will be filled
with the pre-defined panel colours.
VIDEO
Processing
Converter
Path 1
Scaler
Output H Start
0 to 1919
To set the Output H Start control, enter a value between 0 and 1919
into the Output H Start field.
5.1.2.36. Setting the Output H Stop
The Output H Stop control determines where to place the selected portion of the input image onto the
output video raster. The Output H Stop control defines the ending horizontal position for video content
on the output image raster. The input image will be stretched to fill the width defined by Output H Start
and Output H Stop. Areas of the output image raster that are not filled with video content will be filled
with the pre-defined panel colours.
VIDEO
Processing
Converter
Path 1
Scaler
Output H Stop
0 to 1919
To set the Output H Stop control, enter a value between 0 and 1919
into the Output H Stop field.
5.1.2.37. Setting the Output V Start
The Output V Start control determines where to place the selected portion of the input image onto the
output video raster. The Output V Start control defines the starting vertical position for video content
on the output image raster. The input image will be stretched to fill the width defined by Output V Start
and Output V Stop. Areas of the output image raster that are not filled with video content will be filled
with the pre-defined panel colours.
VIDEO
Processing
Converter
Path 1
Scaler
Output V Start
0 to 1079
To set the Output V Start control, enter a value between 0 and 1079
into the Output H Start field.
