HD2014, HD2012, HD2011 Video Passport
TM
1RU Multi-Path Video Converter, Frame Synchronizer and Decoder
Page 5-8 Revision 0.1 FRONT PANEL OPERATION
VIDEO
Routing
Source
Path 1
analogIn
bncIn1
bncIn2
bncIn3
bncIn4
dviIn
FlexLeftBNC1
FlexLeftBNC2
FlexLeftBNC3
sfpIn1
sfpIn2
sfpIn3
sfpIn4
Selects an input to be the source of video for processing path #1.
Note that selections for FlexLeftBN1, FlexLeftBNC2 and FlexLeftBN3
will only be presented when a Left Flex processing module is installed in
the unit.
5.1.2. Configuring the Parameters for the Processing Converter Sub-Menu
To access the core video processing parameters, navigate the engineering menu as follows: Video >
Processing > Converter. The HD2014 has four internal video processors. The HD2012 and the
HD2011 has two internal video processors. For the sake of brevity, only controls for PATH 1 will be
shown in the following sections.
5.1.2.1. Monitoring the Audio Delay Status
For each processing path, the audio delay incurred during the conversion process is reported as part of
the overall audio monitoring process. Select AUDIO DELAY STATUS to determined embedded audio
processing delay.
VIDEO
Processing
Converter
Path 1
Audio Monitor
Audio Delay Status
When selected, the audio delay through the processing path is
reported in microseconds (us). Divide the number presented by 1000
to determine the delay in milliseconds (ms).
