HD2014, HD2012, HD2011 Video Passport
TM
1RU Multi-Path Video Converter, Frame Synchronizer and Decoder
Page 3-2 Revision 0.1 TECHNICAL SPECIFICATIONS
3.1.5. Fiber Inputs
Number of Inputs: 4
Connector: LC/UPC
Form Factor: Dual Optical SFP Receiver (support for single mode and multi-mode fiber RX)
Wavelength: 1260-1620 nm
Data Rate: Auto-sensing SD and HD (270 Mbs and 1.5 Gbs)
Formats: 525i/59.94, 720p/59.94, 1080i/59.94, 625i/50, 720p/50, 1080i/50
Receiver Sensitivity -22 dBm @ 1.485 Gb/s
Max Input Power -1 dBm
3.1.6. Fiber Outputs
Number of Outputs: 4
Connector: LC/UPC
Form Factor: Dual Optical SFP Transmitter (single mode fiber support)
Wavelength: 1310 nm
Data Rate: SD and HD (270 Mbs and 1.5 Gbs)
Format: 525i/59.94, 720p/59.94, 1080i/59.94, 625i/50, 720p/50, 1080i/50
Optical Power - 2 dBm nominal
3.1.7. DVI /Analog Video Inputs
Number of Inputs: 1
Connector: DVI-I (Female)
Breakout Cables: Supply DVI-D signals directly when interfacing DVI signals only.
Use DVI-I → DVI-D and 5x RGBHV BNCs break-out cable when itnerfaceing
component analog video signals (optional accessory # WPDVI-DVIBNC5)
Pr/R supplied to RED wire
Pb/B supplied to BLUE wire
Y/G or composite supplied separately to dedicated
rear panel BNC
Standards DVI-D: 1080p/720p @ 59.94 HZ (no HDCP).1080p inputs are interlaced to 1080i.
DVI-D: 1080p/720p @ 50 Hz (no HDCP). 1080p inputs are interlaced to 1080i.
3.1.8. DVI /Analog Video Outputs
Number of Outputs: 1
Connector: DVI-I (Female)
Breakout Cables: DVI OUT 1 – Full screen program.
DVI OUT 2 – Optional multi-viewer output.
Use DVI-D “Y Cable” (Part #WPDVI-DVI2 optional accessory) when access to
DVI OUT 2 is desired.
Use DVI-I → 2x DVI and 5x RGBHV BNCs (WPDVI-DVIBNC5 optional
accessory) when access to component analog video out is desired
Pr/R supplied to RED wire, Pb/B supplied to BLUE wire
Y/G supplied separately to dedicated
rear panel BNC
Standards: DVI-D Out 1 (Full screen DVI output): 1080i/720p @ 59.94 Hz (no HDCP)
DVI-D Out 2 (Multi-viewer output)
