evertz HD2012 - Technical Description; Specifications

HD2014, HD2012, HD2011 Video Passport
TM
1RU Multi-Path Video Converter, Frame Synchronizer and Decoder
TECHNICAL SPECIFICATIONS Revision 0.1 Page 3-1
3. TECHNICAL DESCRIPTION
3.1. SPECIFICATIONS
3.1.1. Coax Inputs
Number of Inputs: 4
Connector: BNC per IEC 61169-8 Annex A
Input Equalization: 300m @ 270 Mbs with Belden 1694A or equivalent
100m @ 1.5 Gbs with Belden 1694A or equivalent
Return Loss: > 15 dB to 1.5 GHz
Data Rate: Auto-sensing SD and HD (270 Mbs & 1.5 Gbs)
Formats: 525i/59.94, 720p/59.94, 1080i/59.94, 625i/50, 720p/50, 1080i/50
3.1.2. CVBS IN, Y/G Inputs
Number of Inputs: 1
Supply CVBS when configured to operate with CVBS analog video inputs
Supply Y/G when configured to operate with component analog video input
Connector: BNC per IEC 61169-8 Annex A
Signal Level: 1V nominal
Impedance: 75 ohm
Standard NSTC/PAL
Freq Lock Range +/- 50 ppm
Return Loss: > 35dB to 10 MHz
3.1.3. Coax Outputs
Number of Outputs: 4
Connector: BNC per IEC 61169-8 Annex A
Signal Level: 800 mV nominal
DC Offset: 0V ± 0.5V
Rise/Fall Time: 270 ps nominal
Overshoot: < 10% of amplitude
Return Loss: > 15 dB to 1.5 GHz
Wide Band Jitter: < 0.20 UI
Format: 525i/59.94, 720p/59.94, 1080i/59.94, 625i/50, 720p/50, 1080i/50
3.1.4. CVBS OUT, Y/G Outputs
Number of Inputs: 1
CVBS supplied when configured for CVBS out
Y/G supplied when configured for component out
Connector: BNC per IEC 61169-8 Annex A
Signal Level: 1V nominal
Impedance: 75 ohm
Standard NSTC/PAL
DC Offset 0V +/- 50 mV
Return Loss: > 35dB to 10 MHz
SNR > 75 dB
