FRONT PANEL OPERATION Revision 0.1 Page 5-37
5.1.7.2. Setting the Reference Format
The Reference Format control enables the user to select the reference format for the HD201x. The
user can select either NTSC or PAL to be set as the reference format. The HD201x supports bi-level
reference inputs only.
Video
Octoplus
referenceFormat
Ntsc
pal
Bi-level NTSC reference, composite NTSC, or PAL signals may be
applied as a valid reference signal.
5.1.7.3. Setting the Reference Mode
The Reference Mode control enables the user to select the reference mode for the HD201x. To set
the reference mode, select either internal or external from the Reference Mode control. Select external
when supplying the HD201x an external reference signal. Select internal when the HD201x is intended
to operate as a self-locking system.
Video
Octoplus
referenceMode
Internal
External
Selecting Internal enables the HD201x to operate as a self-locking
system. Selecting External enables the user to apply and lock to an
external bi-level reference.
5.1.8. Configuring the Test Generator
5.1.8.1. Setting the Test Signal Generator Format
The HD201x has an internal video test signal generator on which you can select the video format. You
can also overlay user defined text on the test pattern signal to assist with source or truck identification.
Video
Test Gen
format
525i5994
1080i5994
720p5994
625i50
1080i50
720p50
The formats mentioned below are available for selection:
525i5994
1080i5994
720p5994
625i50
1080i50
720p50
