Appendix A: Wiring and Breaker Requirement
Appendix A: Wiring and Breaker Requirement
126
Inverter breaker and switch
EV-SB communication terminal (Purchase separately)
No.
11
Port Pin
Pin 1: RESERVE
Pin 2: RESERVE
Pin 3: CAN_L
Pin 5: RS485_BI_A
Pin 4: CAN_H
Pin 8: GND
Pin 7: +12 V
Pin 6: RS485_BI_B
INV
Communication
terminal
12
13
Pin 1: DRY_GEN
Pin 2: GEND_GEN
Pin 3: RS485_RESERVE_A
Pin 5: RESERVE
Pin 4: RS485_RESERVE_B
Pin 8: STOP_NO-
Pin 7: STOP_NO+
Pin 6: RESERVE
Pin 1: NO_1
Pin 2: COM_1
Pin 3: NC_1
Pin 5: CON_2/3
Pin 4: NO_2
Pin 8: NC_3
Pin 7: NO_3
Pin 6: NC_2
Terminals
Pin 1: CT1+
Pin 2: CT1-
Type
CAT5 or
better
CAT5 or
better
Shielded,
twisted pair
Range
24-18 AWG
24-18 AWG
24-16 AWG
14
AUX1
terminal
AUX2terminal
CT1 terminal
Strip Length
Torque
(in-lbs)
18-16 AWG
0.24 in / 6 mm 1.8
24-16 AWG
0.24 in / 6 mm
1.8
0.24 in / 6 mm
1.8
/ / /
Pin 1: CT2+
Pin 2: CT2-
Shielded,
twisted pair
15
CT2 terminal
/ / /
Pin 1: CT3+
Pin 2: CT3-
Shielded,
twisted pair
16
CT3 terminal
/ / /
Pin 1: CT L1A+
Pin 2: CT L1A-
Shielded,
twisted pair
17
CT L1A terminal
/ / /
No. Port Pin
Terminals
Pin 1: CT L1B+
Pin 2: CT L1B-
Type
Shielded,
twisted pair
Range
18
CT L1B terminal
Strip Length
Torque
(in-lbs)
/ / /
Pin 1: CT L2A+
Pin 2: CT L2A-
Shielded,
twisted pair
19
CT L2A terminal
/ / /
Pin 1: CT L2B+
Pin 2: CT L2B-
Shielded,
twisted pair
20
CT L2B terminal
/ / /
SourceDescriptionComponent
No.
1
Emergency
stop switch
Normally closed (NC) contact
The UL certification is required for the emergency stop switch.
Purchase
separately
127
DescriptionComponent
No.
1
Grid breaker
2
Emergency
stop switch
Normally closed (NC) contact
The UL certification is required for the emergency stop switch.
Amps Part Number Description
100 CSR2100 Eaton # CSR2100: 100 A / 240 V, 25 kAIC, 2-Pole
125 CSR2125N Eaton # CSR2125N: 125 A / 240 V, 25 kAIC, 2-Pole
150 CSR2150N Eaton # CSR2150N: 150 A / 240 V, 25 kAIC, 2-Pole
175 CSR2175N Eaton # CSR2175N: 175 A / 240 V, 25 kAIC, 2-Pole
200 CSR2200N Eaton # CSR2200N: 200 A / 240 V, 25 kAIC, 2-Pole
100 BW2100 Eaton # BW2100: 100 A / 240 V, 10 kAIC, 2-Pole
125 BW2125 Eaton # BW2125: 125 A / 240 V, 10 kAIC, 2-Pole
150 BW2150 Eaton # BW2150: 150 A / 240 V, 10 kAIC, 2-Pole
175 BW2175 Eaton # BW2175: 175 A / 240 V, 10 kAIC, 2-Pole
200 BW2200 Eaton # BW2200: 200 A / 240 V, 10 kAIC, 2-Pole
100 BWH2100 Eaton # BWH2100: 100 A / 240 V, 25 kAIC, 2-Pole
125 BWH2125 Eaton # BWH2125: 125 A / 240 V, 25 kAIC, 2-Pole
150 BWH2150 Eaton # BWH2150: 150 A / 240 V, 25 kAIC, 2-Pole
175 BWH2175 Eaton # BWH2175: 175 A / 240 V, 25 kAIC, 2-Pole
200 BWH2200 Eaton # BWH2200: 200 A / 240 V, 25 kAIC, 2-Pole
EV-SB breaker and switch (Purchase separately)
