3 Specification
3.1 Specification of EVERVOLT Hybrid Inverter
8
PV Input
AC Input/Output
Start input voltage [V]
Model
Max. Inverter PV Power[W]
15200
Max.DC voltage [V]
Norminal DC operating voltage [V]
Max. input current [A]
Max. short circuit current [A]
MPPT voltage range [V]
MPPT voltage range [V](full load)
11400
550
360
A:16/B:16/C:16
A:20/B:20/C:20
90-500
120
235-500
EVHB-I7
AFCI
No. of MPP trackers
Strings per MPP tracker
DC disconnection switch
3
Yes
Yes
A:1/B:1/C:1
General Data
General
Topology
Dimensions with Safety Switch
Weight with Safety Switch [lb(KG)]
Cooling concept
33.1*15.7*5.7840*400*145
75 (34)
Natural convection with internal fan
Transformerless
Communication
Revenue Grade Data, ANSIC12.20
Warranty [Years]
RS485, CAN, WIFI
Optional
12
(WxHxD) [in(mm)]
Maximum output fault peak current
Model
Norminal AC power [VA]
7608
Max. apparent AC power [VA]
Rated grid voltage [V]
Rated grid Frequency [Hz]
Norminal AC current [A]
Max. AC current [A]
Maximum output fault current and
7608
240
50/60
31.7
48/90
515/5
Displacement power factor
Total harmonic distortion
Parallel operation
0.8 leading to 0.8 lagging
<3%
Yes
duration [A/ ms]
and duration [A/ ms]
31.7
(THD, rated power)
Battery safety instructions
EVERVOLT Hybrid inverter should be coupled with a high voltage battery.
The battery must comply with UL 1973 and must be EVERVOLT certified.
As accumulator batteries may contain potential electric shock and short-
circuit current dangers, to avoid accidents that might be thus resulted, the
following warnings should be observed during battery replacement:
Ÿ Risks of explosion:
Do not subject the battery module to heavy impacts.
Do not crush or puncture the battery module.
Do not dispose of the battery module in a fire.
Ÿ Risks of fire:
Do not expose the battery module to temperatures in excess of 140°F.
Do not place the battery module near a heat source, such as a fireplace.
Do not expose the battery module to direct sunlight.
Do not allow the battery connectors to touch conductive objects such as
wires.
Ÿ Risks of electric shock:
Do not disassemble the battery module.
Do not touch the battery module with wet hands.
Do not expose the battery module to moisture or liquids.
Keep the battery module away from children and animals.
Ÿ Risks of damage to the battery module:
Do not expose the battery module to liquids.
Do not subject the battery module to high pressures.
Do not place any objects on top of the battery module.
EVHB-I7
EVHB-I7
Max. Recommended PV Power
[MPPT] [W]
