331
GEARCASE – STANDARD ROTATION
GEARCASE ASSEMBLY
13
To install upper driveshaft into lower driveshaft,
position new retainers (circlip type) on upper
driveshaft as shown.
Hold lower retainer and align upper driveshaft with
lower driveshaft. Force upper driveshaft down
until seated. Driveshaft should lock in place.
1. Retainer(s) 005412
005413
1
Upper Driveshaft Installation 0054
