TRIM AND TILT
ELECTRICAL CIRCUIT TESTS
14
Single Piston System
Use the following guidelines to check a single pis-
ton trim/tilt unit that is not working correctly.
Cylinder Leakdown:
• Manual release valve seals
• External leaks
No reverse lock:
• External leaks
No operation, motor runs:
• Manual release valve open
• Fluid level low
• Pump coupler
• Hydraulic pump
No tilt down:
• Manual release valve
• Fluid level
Slow performance:
• Manual release valve
• Fluid level low
• Mechanical binding
• Electric motor
• Hydraulic pump
Unit locked in tilt up:
• Mechanical binding
• Hydraulic pump
ELECTRICAL CIRCUIT
TESTS
Relay Testing
When the trim-UP button is pressed, the UP relay
is energized and connects the blue trim motor
wire to the battery positive (+) terminal. The green
trim motor wire remains grounded. When the but-
ton is released, the blue trim motor wire returns to
a grounded position.
When the trim-DOWN button is pressed, the
DOWN relay is energized and connects the green
trim motor wire to the battery positive (+) terminal.
The blue motor wire remains grounded. When the
button is released, the green trim motor wire
returns to a grounded position.
Refer to TILT/TRIM RELAY TEST on p. 145 for
relay testing procedure.
Trim and Tilt Motor Current Draw
Tests
Careful analysis of the electric motor's current
draw and trim/tilt unit operating speed aids evalu-
ation of the electric motor and certain mechanical
components.
Use a battery rated at 360 CCA (50 Ah) or higher
that is in good condition and fully charged to per-
form this test.
IMPORTANT: Specifications are for static
hydraulic tests. DO NOT attempt to perform the
following tests while the boat is moving.
