163
ELECTRICAL AND IGNITION
ELECTRIC STARTER SERVICING
7
To test the assembly and operation of the starter,
refer to No Load Current Draw Test on p. 142.
Starter Installation
Apply Locquic Primer and Nut Lock to the threads
of the four starter mounting screws. Position the
starter and install the screws and lock washers.
First, tighten the top two screws, then the bottom
two screws, to a torque of 168 to 192 in. lbs. (19.0
to 21.5 N·m).
Attach starter positive (+) cable to post with lock
washer and nut; tighten securely. Coat connec-
tions with Black Neoprene Dip.
1. Screws 005373
11
