Ewellix THG - TLT20 Telemag Telescopic Pillar; Technical Data

48
THG/TLG/TLT
2
Telescopic pillars
TLT20
Telemag telescopic pillar
Technical data
Benets
• Verysmallbuilt-indimension
• Powerful
• Highspeed
Standards
• EN/IEC60601–1
• UL60601–1
1)
Fordetails,pleaseseebendingloaddiagrams(⮑ page 4)
Unit TLT20 – A3
Ratedpushload N 5000
Ratedpullload N 0
Bendingload Nm upto500
1)
Speed(fullloadtonoload) mm/s 18to28
Telescopicpillarversion #ofsection 3-section
Stroke mm 300to700
Retractedlength mm 0,5×S+130
Voltage VDC 24
Power W 312
Current A 2×6,5
Dutycycle:intermittentoperation min. 1min./9min
Ambienttemperature °C +10to+40
Typeofprotection IP 00
Protectionclass – SELV
Typeofcontrol – electrical
Weight kg 15to30
