Chapter 4
Extension Cards
In addition to the card reference, each type of Extension Card bears a visual compatibility
symbol on its front panel. The visual symbols are shown in the table below:
●●○○ 2 first slots only (A)
●●●● In any slot (X)
○○●●
2 last slots only (B)
An example of hardware configuration is shown in the picture below:
Base Unit Flexy 201 featuring 3 different Extension Cards.
Slot compatibility markings.
Page 23 / 40 eWON Flexy - Base Units | IG 014
