BASIC PART IDENTIFICATION
The parts diagram on the following page shows the location of key parts and baler controls. Some of the parts require installation.
These parts have been shipped packed inside the baler. As you read the description of each part and control, find that part on your baler
to familiarize yourself with its location.
BASIC PART IDENTIFICATION
1. Bale Chamber 25. HOPPER OVER FILL LIMIT LOWER-UPPER - 2
Position Selector Switch
2. Retractable Dogs 26. BALER PHOTO EYE OFF-ON - 2 Position
Selector Switch
3. Removable Shear Blade With 4 Cutting Edges 27. REVERSE Button - Yellow
4. Feed Opening 28. Pilot Valve
5. Platen 29. Relief Valve
6. Wiper 30. Oil Reservoir
7. Access Panel (Rear of Baler) 31. Pump
8. Cylinders (Inside) 32. Motor
9. Bale Tie Light 33. Drain Plug (Optional Heater)
10. Six Wire Tie Slots 34. Temperature/Sight Gauge
11. Door 35. Breather Cap
12. Door Latch 36. Oil Filter
13. Turnbuckle - Ratchet 37. Clean Out Tool
14. 6 Wire Guides (Under Baler)
15. Control Panel
16. Photo Eye
17. Electrical Enclosure
18. BALER Power Disconnect Switch
NOTE: This is not the MAIN Disconnect Switch
19. EMERGENCY STOP - Red
20. FORWARD Button - Green
21. SYSTEM - 3 Position Key Switch and Key HAND-
OFF-AUTO
22. SHORT STROKE OFF-ON - 2 Position Selector
Switch
23. CONVEYOR OFF-0N - 2 Position Selector Switch
24. CONVEYOR ON OVERRIDE - Push Button
