43
MAIN BALER
REF. NO. PART NO. DESCRIPTION QTY.
1 P-1035 Nylock Nut 3
2 M-1050 Dog-Standard 3
3 P-1095 Bolt 3
4 P-1037 Gr. 8 Bolt – Torque 212 ft. lbs. 5
5 P-1038 Flat Washer 5
6 M-1056 Shear Edge 1
M-6007 Shim Shear Edge VAR
7 P-1394 Socket Head Shoulder Screw 2
8 A-1153 Scraper --- Up to Serial Number EX2359 1
A-1806 Scraper w/ Doubler Plate--- Serial Number EX2360 and Up 1
9 P-1524 Spring Extension --- Up to Serial Number EX2359 2
12 P-1024 Flat Washer 2
13 P-1025 Split Lock Washer 2
14 P-1016 Bolt 2
15 A-1475 Rear Cover 1
16 M-2978 Door Hinge Pin 1
17 A-1148 Hinge Limit Cam 1
18 P-1128 Flat Washer 2
19 P-1035 Nylock Nut 3
20 P-1031 Bolt 3
21 A-2201 Door 1
22 A-1797 Door Latch 1
23 M-3009 Latch Pin 1
24 A-1147 Latch Limit Cam 1
25 M-3046 Extended Latch Pin 1
26 A-1008 Wire Guide 6
27 P-1016 Bolt – Up to Serial Number EX2424 12
P-1023 Nylock Nut --- Serial Number EX2425 and Up 12
28 P-1025 Split Lock Washer -- up to Serial Number EX2424 12
29 P-1024 Flat Washer 12
To Next Page
