BALE EJECTION
The bale is ready to be ejected from the chamber after the machine has stopped with the BALE TIE OFF LIGHT illuminated and the
bale has been tied following the previous instructions.
All persons must be clear from the front of the baler when the bale is being ejected. Serious injury could result
from the bale falling onto the pallet.
1. Turn the SYSTEM key switch to the HAND position.
2. Depress the REVERSE button and retract the platen 3” to 4” (75 mm to 100 mm) from the bale.
The bale chamber door is under pressure and may spring open suddenly when the door latch is loosened. Stand
clear of the swing path of the door as it is being opened.
3. Open the bale chamber door completely to activate the safety interlock system.
4. Place a fork lift in front of and lower than the door opening for the bale to land on and be moved away with once it is ejected.
5. Push the FORWARD button. Keep depressing it until the platen reaches full extension and the bale is ejected.
6. Depress the REVERSE button and hold to fully retract the platen.
7. Turn the SYSTEM key switch to the OFF position. Turn the Baler power disconnect switch OFF and lock out.
Observe proper Lock Out/Tag Out procedures before cleaning the baler.
8. After the bale has been removed, clear the inside of the baler chamber and the area of debris.
9. Clean wire guides if necessary using the clean out tool provided.
10. Close and secure the bale chamber door to activate the safety interlock system.
11. Turn the SYSTEM key switch to AUTO and begin forming another bale..
