INSTALLATION INSTRUCTIONS
It is the responsibility of the installer of this baler to install it in accordance with applicable codes, local ordinances, and the
manufacturer's recommendations. The baler must also be installed in accordance with ANSI Z 245.5 (Baling Equipment- Safety
Requirements for Install, Maintenance and Operation). This must be signed off upon completion of installation, sign off is located in
the disconnect box.
It is important that the installers of this baler follow the installation instructions in the order in which they follow.
All persons involved in the installation of this baler should read the manual completely before proceeding.
ELECTRICAL REQUIREMENTS
All wiring must be in accordance with local and national electrical code regulations.
Check the voltage and frequency marking at the installation site MAIN supply disconnect box, so it is certain that the electrical current
characteristics (voltage, etc.) are compatible with those of the baler.
If not, a qualified electrician must take whatever steps are necessary to make the voltage compatible.
Motor Horsepower Line Voltage Motor Amps
20 HP, 3 Phase 230 Volts 54 Amps Full Load
460 Volts 27 Amps Full Load
INITIAL SET UP
After the baler arrives, inspect the overall condition of the baler for damage during shipping. Remove all the loose parts and
information papers.
Make sure that all parts required for assembly have been received. If any items are missing or appear damaged, contact your EXCEL
Manufacturing representative immediately.
INSTALLATION SITE
Careful consideration should be given to the site selected for the baler. Refer to Diagram A on page 3 to determine the amount of room
required to operate the baler. Ample room must be provided to load the baler feed opening, remove a bale from the baler, and obtain
access to the back and sides of the baler for maintenance work and servicing.
Use extreme caution when moving the baler into position. Watch for all persons who may be in the path of the
baler and moving equipment.
BREATHER CAP INSTALLATION
Remove the Breather Cap from the baler’s electrical enclosure (Refer to Diagram B, Item 17). Remove the shipping plug from the oil
reservoir and install the Breather Cap. For the Breather Cap installation location see Item 35, Diagram B.
