17
2. Drill or punch a hole in the electrical enclosure to allow the electrical power line to enter the box. Protect parts from metal chips.
After drilling or punching holes in the electrical box, extract all metal filings or chips from the box. Do not blow
them out or premature contactor failure will result!
3. Run electrical power lines from the customers MAIN disconnect switch to the electrical box.
4. Connect the electrical power line as shown in Diagram G on the next page.
