Panel:
LED Display
5 digits, red 7-segment display, 25.4 mm height.
Multi-display: Weighing mode / Partial External Calibration / Battery status display,
Gross, Net, Hold, and Power-saving status display.
Status Indicators
“Charging” indication. The indicator shows “Red” while charging and shows
“Green” after completing the charging cycle.
During charging: red light red and green light green light
“Low Battery” indication. When the indicator flashes, the battery needs to be
recharged.
“Unit” indication. The first unit is active when the indicator is on. The second
unit is enable when the indicator is off.
When the “-” symbol is displayed across all displayed digits, the scale is in its power-saving
mode. Press any key or place an object on the hook to continue weighing.
The crane supports three units including kg, lb and t. Use to set according
to demand.
If the first unit and the second one are the same, the “unit” symbol won’t response.
Explanations above are EXCELL Standard Edition.
1-3 Power Source
Power Selection
6 V / 10 Ah rechargeable battery
Input AC 110 V / 230 V (± 10%)
Output DC 10 V / 1000 mA adaptor
Power Consumption
Full load : DC 80 mA ± 10% (System + Load Cell),
Power-saving mode : DC 40 mA ± 10%.
The fully charged battery can be used up to around 120 hours.
Low Battery Indicator
When the indicator flashes, the battery needs to be recharged for more than 10 hours.
The scale will be power off automatically after 1 to 2 hours and enters into self-protection
mode if the battery is not charged. Please fully recharge the battery before using the scale
again.
