Introducing the FTB-1v2 and FTB-1v2 Pro

6 FTB-1v2 and FTB-1v2 Pro

Security slot for

Kensington lock

Left panel

Dual carrier and

FTB double-depth

module

High-power dual

carrier

AC/DC power adapter connector
