Maintenance

288 FTB-1v2 and FTB-1v2 Pro

Replacing the Batteries (High-Power Dual Carrier)

To replace (or install) the batteries:

1. Open the battery compartment as follows:

1a. Position the unit vertically so that its back panel is facing you, and

you can see the battery compartment screws on its top.

Screws

Battery compartment

door
